RFID Technology: A Brief Introduction

Ⅰ Introduction RFID is a technology that uses electromagnetic fields to automatically recognize and track tags attached to objects. An RFID system is composed of a small radio transponder, a radio receiver, and a radio transmitter. Catalog Ⅰ Introduction Ⅱ RFID Related Video: Ⅲ RFID Chip 3.1 WHAT IS RFID? 3.2 HOW DOES RFID WORK? 3.3 What Are the Types of RFID Systems  ? Ⅳ RFID Tags 4.1 Definition of RFID Tags 4.2 How RFID Tags Work？ 4.3 Examples of RFID Tags Ⅴ What Does (RFID Reader) Mean? 5.1 What exactly is an RFID Reader  ? 5.2 Readers Types Ⅵ Blocking Wallet 6.1 What Is an RFID-Blocking Wallet? 6.2 How Do RFID-Blocking Wallets Work? 6.3 The 5 Best RFID-Blocking Wallets Ⅶ RFID Asset Tracking  7.1 What Is RFID Asset Tracking  ? 7.2 How Does RFID Asset Tracking  Work? Ⅷ RFID Vs. NFC: The 5 Key Differences Ⅸ FAQ   Ⅱ RFID Related Video:   How RFID Works? and How to Design RFID Chips?     RFID Related Video Description: In this video, we learn about how RFID works and we see how RFID chips are designed. The main concepts such as backscatter modulation and energy harvesting is explained in detail. We start by explaining the RFID technology, in particular passive RFIDs.We discuss the operation of RFID and the magnetic field coupling.Then we look inside the RFID tags and locate the RFID chip and antenna inside the tags.Then we see how RFID chips are designed and explain all different parts of the chip in detail.We discuss the backscatter modulation as well as RF frequencies used in RFID communication.At the end we also provide some information about RFID readers.     Ⅲ RFID Chip 3.1 WHAT IS RFID? RFID is an abbreviation for "radio-frequency identification," and it refers to a technology that uses radio waves to capture digital data encoded in RFID tags  or smart labels (defined below). RFID is similar to barcoding in the sense that data from a tag or label is captured by a device and stored in a database. RFID, on the other hand, has several advantages over systems that use barcode asset tracking software. The most notable difference is that RFID tag data can be read even when the tag is not in direct view, whereas barcodes must be aligned with an optical scanner. If you are thinking about implementing an RFID solution, contact the RFID experts at AB&R® (American Barcode and RFID).   3.2 HOW DOES RFID WORK? RFID systems are made up of three parts: a scanning antenna  , a transceiver, and a transponder. An RFID reader  or interrogator is a device that combines the scanning antenna  and the transceiver. RFID reader  s are classified into two types: fixed readers  and mobile readers  . RFID reader  s are network-connected devices that can be portable or fixed. It transmits signals that activate the tag via radio waves. When activated, the tag sends a wave back to the antenna.  which converts it into data. The RFID tag contains the transponder. RFID tag read range varies depending on factors such as tag type, reader type, RFID frequency, and interference in the surrounding environment or from other RFID tags  and readers,  Tags with a more powerful power source have a greater read range.   3.3 What Are the Types of RFID Systems  ? RFID systems are classified into three types: low frequency (LF), high frequency  (HF), and ultra-high frequency (UHF) (UHF). Microwave RFID technology is also available. Frequencies differ greatly depending on country and region. RFID systems with low frequency. These frequencies range from 30 kHz to 500 KHz, with 125 KHz being the most common.  LF RFID  has relatively short transmission ranges, ranging from a few inches to less than six feet. RFID system with high frequency  These range from 3 MHz to 30 MHz, with 13.56 MHz being the most common HF frequency. The typical range is from a few inches to several feet. RFID  UHF  systems These have a frequency range of 300 MHz to 960 MHz, with a typical frequency of 433 MHz, and can be read from a distance of 25 feet or more. RFID systems that use microwaves These operate at 2.45 Ghz and can be read from a distance of more than 30 feet.   Ⅳ RFID Tags 4.1 Definition of RFID Tags RFID tags are a type of tracking system that uses intelligent barcodes to identify items. RFID stands for "radio frequency identification," and RFID tags  make use of radiofrequency technology. These radio waves send data from the tag to a reader, which then sends the data to an RFID computer program. RFID tags  are commonly used to track merchandise, but they can also be used to track vehicles, pets, and even Alzheimer's patients. An RFID tag is also known as an RFID chip. 4.2 How RFID Tags Work？ An RFID tag transmits and receives data via an antenna  and a microchip, which is also known as an integrated circuit or IC. The RFID reader  's microchip is programmed with whatever information the user desires. What exactly is an RFID tag? RFID tags are classified into two types: battery-powered and passive. Battery-operated RFID tags.  as the name implies, use an onboard battery as a power source, whereas passive RFID tags  do not, instead of relying on electromagnetic energy transmitted from an RFID reader,  RFID tags  powered by batteries are also known as active RFID tags,  Passive RFID tags  transmit data at three different frequencies: 125–134 KHz, also known as Low Frequency (LF), 13.56 MHz, also known as High Frequency (HF) and  Near-Field Communication  (NFC), and 865–960 MHz, also known as Ultra High Frequency (UHF) (UHF). The range of the tag is affected by the frequency used. When a reader scans a passive RFID tag, it sends energy to the tag, which powers it up enough for the chip and antenna  to relay information back to the reader. The reader then sends this data to an RFID computer program for interpretation. Passive RFID tags  are classified into two types: inlays and hard tags. Inlays are typically thin and can be adhered to a variety of surfaces, whereas hard tags are, as the name implies, made of a hard, durable material such as plastic or metal.Transponders are much more battery-efficient than beacons because they only activate when they are close to a reader. Figure1:antenna 4.3 Examples of RFID Tags Because an active RFID is constantly transmitting a signal, it is an excellent choice for those seeking real-time trackings, such as in tolling and real-time vehicle tracking applications. They are a costly product, but they have a long read range, which may be preferred depending on the application. Passive RFID tags.  which cost around 20 cents each, are a much more cost-effective option than active  RFID tags ,  As a result, they are a popular choice for applications such as supply chain management, race tracking, file management, and access control. While a passive RFID tag does not require a direct line of sight to the RFID reader.  its read range is much shorter than that of an active RFID tag. They are small, lightweight, and have the potential to last a lifetime. Active RFID tags are better suited for applications requiring durability because they have a larger, more rugged design than passive RFID tags,  They are commonly used in toll payment transponder systems, cargo tracking applications, and even personal tracking devices. Figure2:Examples of RFID Tags Ⅴ What Does (RFID Reader) Mean? 5.1 What exactly is an RFID Reader  ? A radio frequency identification reader (RFID reader) is a device that collects data from RFID tags that are used to track individual objects. Data is transferred from the tag to a reader using radio waves. RFID is a technology that, in theory, is similar to bar codes. The RFID tag, on the other hand, does not have to be scanned directly, nor does it need to be in direct line of sight of a reader. To be read, the RFID tag must be within the range of an RFID reader.  which can range from 3 to 300 feet. RFID technology allows several items to be scanned quickly and allows for quick identification of a specific product, even when it is surrounded by several other items. RFID tags have not replaced bar codes due to their high cost and the requirement to individually identify each item.   5.2 Readers Types A passive reader in a Passive Reader Active Tag (PRAT) system only receives radio signals from active tags (battery operated, transmit only). A PRAT system reader's reception range can be adjusted from 1–2,000 feet (0–600 m), providing flexibility in applications such as asset protection and supervision.   An active reader in an Active Reader Passive Tag (ARPT) system transmits interrogator signals and receives authentication responses from passive tags. Active tags activated by an interrogator signal from the active reader are used in an Active Reader Active Tag (ARAT) system. A Battery-Assisted Passive (BAP) tag, which acts like a passive tag but has a small battery to power the tag's return reporting signal, could also be used in this system.Fixed readers  are configured to create a specific interrogation zone that is tightly controlled. This allows for a well-defined reading area when tags enter and exit the interrogation zone. Handheld mobile readers  are available, as well as those mounted on carts or vehicles.   Ⅵ Blocking Wallet If you have RFID-enabled cards, passports, or devices, an RFID-blocking wallet may be necessary to protect your data.   6.1 What Is an RFID-Blocking Wallet? Thieves can steal your credit card information just by standing next to you if you don't have an RFID-blocking wallet. It is possible if you carry a credit card with an RFID chip embedded in it. RFID credit cards allow you to make payments by simply touching the card to a scanner rather than swiping it across or inserting it into a terminal. They're made for ease of use. Imagine someone approaching you and "scanning" the wallet in your back pocket without your knowledge. They could theoretically copy the RFID data and create a clone of your credit card unless it is protected by an RFID-blocking wallet.   6.2 How Do RFID-Blocking Wallets Work? RFID chips have been a source of concern for many years, and not just in credit cards. RFID chips in all US passports issued after 2006 track your photo and information. RFID chips are embedded in metro cards for quick swiping, and RFID chips are implanted in dogs for tracking. RFID chips communicate by using radio waves. An RFID tag with information is embedded in the object, such as a credit card, and an RFID reader  uses radio waves to read the information from the tag. The key point is that RFID chips have tiny electromagnetic fields, which allows them to be read without having to "initiate" communications. The RFID reader  only needs to be close enough to the field to work. As a result, someone could theoretically scan a card through your pocket. And, yes, people have been scanned in the real world in this manner. Check out this Reddit anecdote to see what kind of headache RFID hackers can cause. Fortunately, radio waves can be easily interrupted and blocked, which is how an RFID-blocking wallet works. They encase your credit cards in a radio-interfering material. If the wallet is constructed properly as a Faraday cage, it will block all electromagnetic fields and prevent communication between your cards and RFID scanners. But do YOU really require an RFID-blocking wallet? Most likely not. If your credit cards do not have RFID chips, you obviously do not require one. Even if you do have RFID-enabled cards, the chances of being scanned maliciously are extremely low—-less than 1%, according to some. On the other hand, the possibility exists at all times, and the probability is non-zero.   6.3 The 5 Best RFID-Blocking Wallets Saddleback Passport WalletBig Skinny Slimline WalletTrayvax Original WalletSharkk Rugged WalletRadix One Black Steel   Ⅶ RFID Asset Tracking  As a company that depends on the availability of high-value assets to generate revenue, you understand the significance of asset tracking and effective inventory management. Whether it's inventory, tools, IT equipment, vehicles, or even employees. 7.1 What Is RFID Asset Tracking  ? RFID asset tracking is a technique for automating the management and location of physical assets. It works by loading data onto an RFID tag and attaching it to a relevant asset. This information can range from name, condition, amount, and location. An RFID reader  can capture the stored data by using the RFID tag's repeatedly pulsating radio waves. Eventually, it will be collected in a sophisticated asset tracking system, where the data can be monitored and acted upon. The ability to automate your tracking and monitoring processes seeks to eliminate the highly error-prone methods of pen-and-paper and excel spreadsheets.Among other benefits such as: Tracking multiple assets at any one timeEliminating human interventionCollecting data in real-timeImproving asset visibilityLocating lost or misplaced assetsMaximising accuracy of inventory   7.2 How Does RFID Asset Tracking  Work? The basic principles of how an RFID tracking system works are very similar whether it is used in agriculture to track livestock or in a warehouse to monitor a manufacturer's supply chain. First, you'll need the right tools: RFID Tags (Passive, Active, or Semi-Passive)An AntennaAn RFID ReaderA computer database equipped with Asset Tracking Software The RFID asset tracking process can be divided into four stages once the proper equipment is in place: The data is stored on an RFID tag that has a unique  Electronic Product Code  (EPC) and is attached to an asset. An antenna  detects a nearby RFID tag's signal. An RFID reader is wirelessly connected to the antenna  and receives the data stored on the RFID tag. The data is then transmitted by the RFID reader to an asset tracking database, where it is stored, evaluated, and acted upon. The initial process is relatively simple, depending on how you choose to deploy your RFID asset tracking system. However, there are a variety of factors to consider when selecting the right hardware.   Ⅷ RFID Vs. NFC: The 5 Key Differences Even though both technologies appear similar on the surface, there are five key differences between them. The Reading Range NFC technology operates on a limited range, also known as proximity. RFID, on the other hand, can read tags from up to 10 meters away, making it the best solution for vehicle identification and access. Check out our Automatic Vehicle Identification Guide if you want to learn more about long-term solutions. Communication Because NFC is capable of two-way communication, it can provide novel and complex solutions such as card emulation and peer-to-peer. Speed With NFC technology, unlike RFID tags.  only one tag can be read at a time. As a result, RFID tags are often better suited to environments with a high concentration of trackable components. Asset management in a manufacturing facility or tracking fast-moving vehicles is two examples. Data NFC technology stores and transmits a variety of data types. NFC devices, with their larger storage capacity, can store and transmit more data than RFID devices, which can only carry simple ID information. As a result, NFC is better suited to environments where payment details, membership, and ticket information, among other things, must be transferred. The cost-effectiveness NFC-based readers  are less expensive than long-range RFID solutions due to their limited reading range. As a result, NFC is an excellent choice for businesses on a tight budget who still require a high-quality solution. Ⅸ FAQ 1. Can you be tracked through RFID? The answer was an electronic lock, and the company has given its handful of employees the option of using an electronic key or getting an RFID chip implanted in their arm. "It can't be read, it can't be tracked, it doesn't have GPS," Darks said. 2. Can RFID be hacked? RFID hackers have demonstrated how easy it is to get hold of information within RFID chips. As some chips are rewritable, hackers can even delete or replace RFID information with their own data. ... It's easy to purchase the parts for the scanner, and once built, someone can scan RFID tags and get information out of them. 3. Why is RFID bad? The other problem with RFID chips versus, say, embedded smart chips is that as wireless devices they don't need to be near the reader to be read. Smart chips, on the other hand, need to be put next to, or into, a reader, so they aren't as susceptible to being sniffed in the open. 4. How is RFID powered? Active RFID tags have a transmitter and their own power source (typically a battery). ... Instead, they draw power from the reader, which sends out electromagnetic waves that induce a current in the tag's antenna. Semi-passive tags use a battery to run the chip's circuitry, but communicate by drawing power from the reader. 5. What is RFID example? For example, an RFID tag attached to an automobile during production can be used to track its progress through the assembly line, RFID-tagged pharmaceuticals can be tracked through warehouses, and implanting RFID microchips in livestock and pets enables positive identification of animals. 6. How do I know if I have an RFID chip? The best way to check for an implant would be to have an X-ray performed. RFID transponders have metal antennas that would show up in an X-ray. You could also look for a scar on the skin. Because the needle used to inject the transponder under the skin would be quite large, it would leave a small but noticeable scar. 7. Do credit cards have RFID? RFID-enabled credit cards - also called contactless credit cards or “tap to pay” cards - have tiny RFID chips inside of the card that allow the transmission of information. ... Though many new credit cards are RFID-enabled, not all of them are. On the other hand, all newly-issued credit cards come with an EMV chip.

Introduction Radio Frequency Identification (RFID) is a type of automatic identification technology that uses radio frequency to carry out wireless non-contact two-way data communication, with recording media (electronic tags or radio frequency cards) to read and write. The purpose is identifying the target and making data exchange. This is an extremely complex system, so it involves many parameters. Next, we will introduce several important parameters in detail. What is RFID? How RFID works? Catalog Introduction Ⅰ RFID Parameters Explained 1.1 Rx Sensitivity 1.2 SNR (Signal-to-Noise Ratio) 1.3 Tx Power 1.4 ACLR/ACPR 1.5 Modulation Spectrum/Switching Spectrum 1.6 SEM (Spectrum Emission Mask) 1.7 EVM (Error Vector Magnitude) 1.8 Interference Indicators 1.9 Dynamic Range, Temperature Compensation and Power Control Ⅱ FAQ Ⅰ RFID Parameters Explained Radio frequency identification involves many settings, that is, parameter selections. What are they? Here gives you the detailed descriptions as following mentioned. 1.1 Rx Sensitivity Receiving sensitivity is one of the most basic concepts, characterizes the lowest signal strength that the receiver can recognize without exceeding a certain bit error rate (BER), which is a general term that follows the definition of the circuit switched (CS) era. In most cases, BER or  Packet Error Rate (PER) will be used to examine the sensitivity. In the Long Term Evolution (LTE) era,  use throughput to define simply. LTE does not have a circuit-switched voice channel, but this is also a real evolution. Because for the first time we no longer use "standardization" such as 12.2kbps RMC (voice coding at 12.2kbps) to measure sensitivity, but the throughput that users can really feel.   1.2 SNR (Signal-to-Noise Ratio) When talking about sensitivity, we often refer to SNR (signal-to-noise ratio), we generally talk about the demodulation SNR of the receiver. We define it as the ability of the demodulator to not exceed a certain bit error rate, that is, SNR threshold for demodulation.So where do S and N come from? S means Signal, or useful signal; N means Noise. The useful signal is generally emitted by the communication system transmitter, and the source of noise is very wide. The most typical one is the famous -174dBm/Hz (natural noise). It is a quantity that has nothing to do with the type of communication system. In a sense, it is actually a noise power density related to temperature. In addition, how much bandwidth do we receive determine the noise, that is, the final noise power is integrated on the bandwidth by the noise power density. 1.3 Tx Power The importance of the transmission power is that the signal from the transmitter needs to pass through the fading of space to reach the receiver. So the higher the transmission power means the longer the communication distance.So should we consider SNR for our transmitted signal? For example, if the SNR of our transmitted signal is very poor, do we receive the same bad?This involves the concept just mentioned, the natural noise we assume that spatial fading has the same effect on both signal and noise (in fact, it is not, the signal can resist fading through coding but noise not) and it acts like an attenuator. For example, we assume spatial fading is -200dB, the transmitted signal bandwidth is 1Hz, the power is 50dBm, and the SNR is 50dB, then what is the SNR received by the receiver?The power of the signal received by the receiver is 50-200=-150Bm (bandwidth 1Hz), and the noise of the transmitter 50-50=0dBm through spatial fading, and the power reaching the receiver is 0-200=-200dBm (bandwidth 1Hz)? At this time, this part of the noise has already been "submerged" under the natural noise -174dBm/Hz. At this time, we only need to consider the "basic component" of -174dBm/Hz to calculate the noise to the receiver. Actually, this is applicable in most cases of communication systems.   1.4 ACLR/ACPR These parameters are explained together because they actually represent part of the "transmitter noise", but these noises are not in the transmitting channel, but the part that the transmitter leaks into the adjacent channels, which can be collectively referred to as "Leakage in the adjacent channel".ACLR and ACPR (actually one thing, but one is called in the terminal test, the other is called in the base station test), both are named after "Adjacent Channel". They both describe the machine pair interference from other equipment. And their power calculation of the interference signal is also based on a channel bandwidth. This measurement method considers the signal leaked by the transmitter and the interference to the equipment receiver of the same or similar standard-the interference signal falls into the receiver band with the same frequency and the same bandwidth. That is, form the same frequency interference to the signal received by the receiver.In LTE, the ACLR test has two settings: EUTRA and UTRA. The former describes the interference among the LTE systems, and the latter considers the interference of the LTE system to the UMTS system. So we can see that the measurement bandwidth of EUTRAACLR is the occupied bandwidth of LTE RB, and the measurement bandwidth of UTRA ACLR is the occupied bandwidth of UMTS signals (FDD system 3.84MHz, TDD system 1.28MHz). In other words, ACLR/ACPR describes a kind of "peer-to-peer" interference: the leakage of the transmitted signal interferes with the same or similar communication system.This definition is significant. For example, in the actual network, there are often signal leakage from neighboring cells from other or in the same region. In other words, the adjacent channel leakage of the system itself is typical for neighboring cells. Therefore, the process of network planning and optimization is actually the process of capacity maximization and interference minimization. In addition, from the other side of the system, the mobile phones of users in crowded people may also become a source of mutual interference.Similarly, in the evolution of communication systems, the goal has always been to "smooth transition", that is, to upgrade and transform existing networks into next-generation networks. Therefore, the coexistence of two or even three generations of systems should consider the interference between different systems. So the introduction of UTRA in LTE is to consider the radio frequency interference to the previous generation system UMTS.   1.5 Modulation Spectrum/Switching Spectrum In the GSM system, Modulation Spectrum and Switching Spectrum also play a similar role to adjacent channel leakage. The difference is that their measurement bandwidth is not the occupied bandwidth of the GSM signal. From a definition point of view, it can be considered that the modulation spectrum is a measure of the interference between synchronous systems, and the switching spectrum is a measure of the interference between asynchronous systems. In fact, if the signal is not gating, the switching spectrum will definitely cover the modulation spectrum.This involves another concept: in the GSM system, the cells are not synchronized, although it uses TDMA. In contrast, TD-SCDMA and later TD-LTE, the cells are synchronized.Because the cells are not synchronized, the power leakage of the rising edge/falling edge of the A cell may fall to the payload part of the B cell, so we use the handover spectrum to measure the interference of the transmitter to the adjacent channel in this state. And in the entire 577us GSM timeslot, the proportion of rising edge/falling edge is very small after all. What’s more, most of the time, the payload of two adjacent cells will overlap in time. In this case, the interference of the transmitter to the adjacent channel can be evaluated by referring to the modulation spectrum. Figure 1. RFID Chip 1.6 SEM (Spectrum Emission Mask) SEM is an in-band indicator, which is distinguished from spurious emission. The latter includes SEM, but the focus is on the spectrum leakage outside the working frequency band of the transmitter. In addition, its introduction is more based on the perspective of EMC (Electromagnetic Compatibility).SEM provides a spectrum template. When measuring the spectrum leakage in the transmitter band, see if there are any points that exceed the template limit. It can be said that it is related to ACLR, but it is not the same. ACLR considers the average power leaked into the adjacent channel, so it uses the channel bandwidth as the measurement bandwidth, and it reflects the "critical noise point" of the transmitter in the adjacent channel. Where SEM reflects the capture of over-standard points in adjacent frequency bands with a smaller measurement bandwidth (usually 100kHz to 1MHz), which reflects the noise-based spurious emission.If you scan the SEM with a spectrum analyzer, you can see that the spurious points on the adjacent channel will generally be larger than the ACLR average. Therefore, if the ACLR indicator itself has no margin, the SEM will easily exceed it. On the other hand, if the SEM exceeds the ACLR, it does not necessarily mean bad. For example, a common phenomenon is that there is LO spurious or a certain clock and LO modulation component (often very narrow bandwidth, similar to dot frequency) in the transmitter link, although ACLR is good, the SEM may exceed the standard.   1.7 EVM (Error Vector Magnitude) EVM is a vector, which means it has amplitude and angle. It measures the error between the actual signal and the ideal signal. This measurement can effectively express the "quality" of the transmitted signal. That is, the farther the point distance of the actual signal to the ideal signal, the greater the error and the greater the modulus of the EVM.Why is the SNR of the transmitted signal not so important? There are two reasons: the first is that it is often much higher than the SNR required for demodulation of the receiver. The second is the condition, that is, the worst case. The transmitter noise has already been submerged under the natural noise after a large spatial fading, and the useful signal is also attenuated to near the demodulation threshold of the receiver.But the "intrinsic SNR" of the transmitter needs to be considered in some cases, such as short-range wireless communication. Even without considering the spatial fading, demodulation of such high-order quadrature modulated signals alone already requires a high SNR. The worse the EVM, the worse the SNR and the higher the difficulty of demodulation. Engineers working on 802.11 systems often use EVM to measure Tx linearity. While engineers working on 3GPP systems, they like to use ACLR/ACPR/Spectrum to measure it.From the origin, 3GPP is the evolutionary path of cellular communication, and from the very beginning it has to pay attention to adjacent channel and alternative channel interference. In other words, interference is the number one obstacle that affects cellular communication rates. Therefore, 3GPP always aims at "minimizing interference" during its evolution, such as frequency hopping in the GSM era, spread spectrum in the UMTS era, and the RB concept in LTE era.The 802.11 system is an evolution of fixed wireless access. It follows the spirit of the TCP/IP protocol and aims at "service first". In 802.11, there use often time division or frequency hopping methods to achieve multi-user coexistence. The network layout is more flexible, and the channel width is also flexible and variable. In general, it is not sensitive to interference (or rather high tolerance).In layman's terms, the origin of cellular communication is to make phone calls, and users who cannot get through the phone will go to the telecommunications; while the origin of 802.11 is the local area network, you just wait at first when the network is not good.So this determines that the 3GPP series must take ACLR/ACPR and other "spectrum regeneration" performance as indicators, while the 802.11 series can adapt to the network environment at the expense of speed.Specifically, "Adapt to the network environment at the expense of speed" means that in the 802.11 series, different modulation orders are used to cope with the propagation conditions. When the receiver finds a signal difference, it immediately informs the opposite transmitter to reduce the modulation order. As mentioned earlier, SNR and EVM in an 802.11 system are highly correlated. To a large extent, a reduction in EVM can improve SNR. In this way, we have two ways to improve the receiving performance: one is to reduce the modulation order, thereby reducing the demodulation threshold; the other is to reduce the transmitter EVM, so that the signal SNR is improved.Because EVM is closely related to the demodulation effect of the receiver, EVM is used to measure the performance of the transmitter in the 802.11 system (similarly, in 3GPP, ACPR/ACLR is the index that mainly affects the network performance). In addition, the deterioration of EVM is mainly caused by non-linearity (for example, AM-AM distortion of PA), so EVM is usually used as a sign to measure the linear performance of the transmitter. Figure 2. RFID 1.7.1 Relations of EVM to ACPR / ACLR It is difficult to define the quantitative relationship between EVM and ACPR/ACLR. From the non-linearity of the amplifier, EVM and ACPR/ACLR should be positively correlated. That is, the AM-AM and AM-PM distortion of the amplifier will amplify the EVM, and also the ACPR/ACLR.However, EVM and ACPR/ACLR are not always positively correlated. For example, Clipping is commonly used in digital IF. It is to reduce the peak-to-average ratio (PAR) of the transmitted signal. The reduction of peak power can help reduce the ACPR/ACLR after passing through the PA. However, clipping will also damage the EVM. Because whether it is clipping (windowing) or using a filter, they all cause damage to the signal waveform, affecting the EVM. 1.7.2 Source Flow of PAR PAR (Peak-to-Average Ratio) is usually represented by a statistical function such as CCDF, and its curve represents the power (amplitude) value of the signal and its corresponding probability of occurrence. For example, if the average power of a certain signal is 10dBm, the statistical probability that it has a power exceeding 15dBm is 0.01%, and we can consider its PAR is 5dB.PAR is an important factor affecting transmitter spectrum regeneration (such as ACLP/ACPR/Modulation Spectrum) in modern communication systems. The peak power will push the amplifier into the nonlinear region and produce distortion. And the higher the peak power, the stronger the nonlinearity.In the GSM era, because of the constant envelope characteristic of GMSK modulation, PAR is 0. When designing GSM power amplifiers, we often push it to P1dB to get the maximum efficiency. After the introduction of EDGE, 8PSK modulation is no longer a constant envelope, so we tend to push the average output power of the amplifier to about 3dB below P1dB, because the PAR of the 8PSK signal is 3.21dB.In the UMTS era, whether WCDMA or CDMA, the PAR is much larger than that of EDGE. The reason is the correlation of the signals in the code division multiple access system. In other words,  when the signals of multiple code channels are superimposed in the time domain, the same phase may occur, and the power will show a peak at this time.The PNR of LTE is derived from the burstiness of the RB. OFDM modulation is based on the principle of dividing multi-user/multi-service data into blocks in both the time domain and the frequency domain, so that high power may appear in a certain "time block". LTE uplink transmission uses SC-FDMA. First, DFT extends the time domain signal to the frequency domain, which is equivalent to "smoothing" the burstiness in the time domain, thereby reducing PAR. Figure 3. RFID Applications 1.8 Interference Indicators The "interference index" here refers to the sensitivity test under various applied interferences in addition to the static sensitivity of the receiver. In fact, it is very interesting to study the origin of these test items.Our common interference indicators include Blocking, Desense, Channel Selectivity, etc. 1.8.1 Blocking Blocking is actually a very old RF indicator, as early as the invention of radar. The principle is to pour a large signal into the receiver (usually the first LNA that suffers the most), making the amplifier enter the nonlinear region or even saturate. At this time, on the one hand, the amplifier gain suddenly becomes smaller, and on the other hand, extremely strong nonlinearity occurs, so the function of amplifying useful signals cannot work normally.Another possible Blocking is actually done through the receiver's AGC. Large signals enter the receiver link, and the receiver AGC will reduce the gain to ensure dynamic range, but the useful signal level entering the receiver is very low. At this time, the gain is insufficient, and the amplitude of the useful signal entering the demodulator is insufficient.Blocking indicators are divided into in-band and out-of-band, mainly because the RF front-end generally has a band filter, which has an inhibitory effect on out-of-band blocking. However, the blocking signal is generally point frequency without modulation. In fact, point-frequency signals without modulation at all are rare in practice. In engineering, it is approximately point-frequency to replace various narrow-band interference signals.For solving Blocking, the key is RF. In other words, it is to expand the dynamic range of receiver. For out-of-band blocking, the rejection of the filter is also very important. 1.8.2 AM Suppression AM Suppression is a unique indicator of the GSM system. From the description point of view, the interference signal is a TDMA signal similar to the GSM signal, synchronized with the useful signal and has delay.This scenario simulates the signal of the neighboring cell in the GSM system. From the point of view that the frequency offset of the interference signal is greater than 6MHz (GSM bandwidth is 200kHz), this is a very typical neighboring cell signal configuration. So we can think that AM suppression is a reflection of the receiver's interference tolerance to neighboring cells in the actual work of the GSM system.Adjacent (Alternative) Channel Suppression (Selectivity)Here we collectively refer to it as "adjacent channel suppression". In the cellular system, in addition to the same-frequency cells, we must also consider adjacent-frequency cells in our networking. The reason can be found in the transmitter index ACLR/ACPR/Modulation Spectrum that we discussed before. Because of the transmitter's spectrum regeneration, there will be strong signals falling into adjacent frequencies (generally, the farther the frequency offset, the lower the level, so the adjacent channel is generally the most affected), and this kind of spectrum regeneration is actually related to the transmitted signal. That is, receivers of the same standard are likely to mistake this part of the regenerated spectrum as a useful signal for demodulation.For example, if two neighboring cells A and B happen to be neighboring frequency cells (such networking methods are generally avoided, here is just a assumption), when a terminal registered in cell A swims to the campus junction of two, but the signal strength of the two cells has not reached the handover threshold, the terminal still maintains cell connection with A, and the ACPR of the B cell base station transmitter is higher. So the terminal’s receiving frequency band has a higher ACPR component of B cell, which overlaps with the useful signal of cell A in frequency. Because the terminal is far away from the base station of cell A at this time, the received signal is weak. At this time, when the ACPR component of cell B enters the terminal receiver, it causes co-channel interference to the original useful signal.If we pay attention to the definition of the frequency offset of the adjacent channel selectivity, we will find that there is a difference between Adjacent and Alternative, which corresponds to the first and second adjacent channels of ACLR/ACPR. It can be seen that the "transmitter spectrum leakage (regeneration)" in the communication protocol and the "receiver adjacent channel selectivity" are actually defined in pairs. 1.8.3 Co-Channel Suppression (Selectivity) Co-frequency interference generally refers to the interference pattern between two cells.According to the networking principles we described earlier, the distance between two cells with the same frequency should be as far as possible. In addition, even if they are farther away, there will be signals leaking to each other, but the difference is in intensity. For the terminal, the signals of the two campuses can be regarded as "correct and useful signals" (of course, there is a set of access specifications on the protocol layer to prevent such false access). Frequency strength of both depends on its co-frequency selectivity. 1.8.4 Summery Blocking is big signal interferes with small signal, but the AM Suppression is small signal interferes with large signal.Single-tone Desense is a unique indicator of the CDMA system. It has a feature: the single-tone is an in-band signal and is very close to the useful signal. In this way, it is possible to generate two kinds of signals falling into the receiving frequency domain: First is due to near-end phase noise of the LO, the baseband signal formed by the mixing of the LO and the useful signal, and the signal formed by the mixing of the LO phase noise and the interference signal. Both will fall within the range of the receiver baseband filter, the former is a useful signal and the latter is interference. Second is due to the nonlinearity in the receiver system. The useful signal (with a certain bandwidth, such as 1.2288MHz CDMA signal) may produce intermodulation with the interference signal on the nonlinear device, falling in the receiving frequency domain and becoming interference.The origin of single-tone desense is that the CDMA system uses the same frequency band as the original analog communication system AMPS, and the two networks coexisted for a long time. So the CDMA system must consider the AMPS system's interference to itself.The explanation of Blocking in theory: the large signal entering the receiver causes the amplifier to enter the nonlinear region, and the actual gain becomes smaller (for useful signals).But it is difficult to explain two scenarios:Scenario 1: The pre-stage LNA has a linear gain of 18dB. When a large signal is injected to make it reach P1dB, the gain is 17dB. If no other influence is introduced (the default LNA NF, etc. have not changed), then the noise figure of the entire system is actually very limited. It is nothing more than the fact that the denominator of the latter-stage NF becomes a little smaller when it is included in the total NF, which has little effect on the sensitivity of the entire system.Scenario 2: The IIP3 of the previous LNA is very high, so it is not affected. The second level gain block is affected (the interference signal makes it reach near P1dB). In this case, the impact of the entire system NF is even smaller.Here is a point of view: the influence of Blocking may be divided into two parts. One part is that the gain mentioned in the textbook is compressed, and the other part is actually that after the amplifier enters the nonlinear region, the useful signal is distorted in this region. This kind of distortion may include two parts, one part is the spectrum regeneration (harmonic component) of the useful signal caused by pure amplifier nonlinearity, and the other part is the Cross Modulation of the large signal modulating the small signal.From this we also put forward another idea: if we want to simplify the Blocking test (3GPP requires frequency sweeping, which is very time-consuming), we may be able to select certain frequency points, which have the greatest impact on useful signal distortion when the Blocking signal appears.From an intuitive point of view, these frequency points may have: f0/N and f0*N (f0 is the useful signal frequency, and N is a natural number). The former is because the N-th harmonic component generated by the large signal in the nonlinear region is just superimposed on the useful signal frequency f0 to form direct interference, and the latter is superimposed on the N-th harmonic of the useful signal f0 and affects the output signal f0.According to Pascal's law, the waveform of the time domain signal is actually the sum of the domain fundamental frequency signal and each harmonic. When the power of the Nth harmonic in the frequency domain changes, the corresponding in the domain is the envelope change of the time domain signal (have distortion). Figure 4. RFID Readers   1.9 Dynamic Range, Temperature Compensation and Power Control These three indicators will only be shown when certain extreme tests are performed, but they themselves represent the most significant part of RF design. 1.9.1 Dynamic Range of the Transmitter The dynamic range of the transmitter characterizes the maximum and minimum transmission power without damaging other transmission indicators. This concept is very broad. If you look at the main effects, you can understand that the linearity of the transmitter is not compromised at the maximum transmission power, and the SNR of output signal is maintained at the minimum transmission power.Under the maximum transmit power, the output is often close to the nonlinear region of active devices at all levels (especially the final amplifier), and the nonlinearity that often occurs is spectral leakage and regeneration (ACLR/ACPR/SEM), modulation error (PhaseError/EVM). The most susceptible at this time is basically the linearity of the transmitter.Under the minimum transmit power, the useful signal output by the transmitter is close to the natural noise of the transmitter, and may even be submerged in the transmitter noise. At this time, what needs to be guaranteed is the SNR of the output signal. In other words, the lower the transmitter noise at the minimum transmit power, the better. 1.9.2 Dynamic Range of the Receiver The dynamic range of the receiver is actually related to the two indicators we talked about before, the first is the reference sensitivity, and the second is the receiver IIP3 (interference indicator).The reference sensitivity actually characterizes the minimum signal strength that the receiver can recognize. We mainly talk about the maximum receiving level of the receiver.It refers to the maximum signal that the receiver can receive without distortion. This distortion may occur at any stage of the receiver, from the previous LNA to the receiver ADC. For the front-level LNA, the only thing we can do is to increase IIP3 as much as possible so that it can withstand higher input power. For the subsequent step-by-step devices, the receiver uses AGC (automatic gain control) to ensure that the useful signal falls on the device within the input dynamic range. Simply put, there is a negative feedback loop: detect the received signal strength (too low/too high)-adjust the amplifier gain (up/down)-the amplifier output signal to ensure that it falls within the input dynamic range of the next stage device.Here we talk about an exception: the front-end LNA of most mobile phone receivers has AGC function. If you study their datasheet carefully, you will find that the front-end LNA provides several variable gain sections, and each gain section has its corresponding noise factor. Generally speaking, the higher the gain, the lower the noise factor. This is a simplified design. The design goal of the receiver RF link is to keep the useful signal input to the receiver ADC within the dynamic range and keep the SNR higher than the demodulation threshold (the SNR is not critical,  but "just enough"). Therefore, when the input signal is large, the front-stage LNA reduces gain, loss NF, and increases IIP3 at the same time. When the input signal is small, the front-stage LNA increases gain, reduces NF, and meanwhile reduces IIP3. Figure 5. RFID Discover 1.9.3 Temperature Compensation Generally speaking, we only have temperature compensation in the transmitter. Of course, the receiver performance is also affected by temperature. On the one hand, the receiver link gain decreases at high temperatures, and NF increases. On the other hand, at low temperatures, receiver link gain increases, and NF decreases. However, due to the small signal characteristics of the receiver, both gain and NF are within the range of system redundancy.It can also be subdivided into two parts: one part is the compensation for the power accuracy of the transmitted signal, and the other part is the compensation for the change in the transmitter gain with temperature.Transmitters of modern communication systems generally perform closed-loop power control (except for the slightly "old" GSM system and Bluetooth system). Therefore, the power accuracy of transmitters calibrated through production procedures actually depends on the accuracy of the power control loop. Generally speaking, the power control loop is a small signal loop, and the temperature stability is very high, so the demand for temperature compensation is not high, unless there are temperature-sensitive devices (such as amplifiers) on the power control loop.Temperature compensation for transmitter gain is more common, which has two common purposes:One is "visible", usually for systems without closed-loop power control (such as the aforementioned GSM and Bluetooth), this type of system usually does not require high output power accuracy, so the system can apply a temperature compensation curve (function) to keep the RF link gain within an interval. So that when the baseband IQ power is fixed and the temperature changes, the RF power output by the system can also be kept within a certain range.The other is "invisible", usually in a system with closed-loop power control. Although the RF output power of the antenna port is precisely controlled by the closed-loop power control, we need to keep the DAC output signal within a certain range (A common example is the need for digital predistortion (DPD) of the base station transmission system), then we need to control the gain of the entire RF link more accurately around a certain value.In the early stage of low accuracy and low cost accuracy requirements, temperature compensation attenuators are more common. Require higher accuracy requirements, the solution generally: temperature sensor + digital attenuator/amplifier + production calibration. 1.9.4 Power Control of the Receiver After talking about dynamic range and temperature compensation, let's talk about a related and very important index: power control.Transmitter power control is a necessary function in most communication systems. Commonly used in 3GPP, such as ILPC, OLPC, and CLPC. In addition, it must be tested in RF design.All transmitter power control purposes include two points: power consumption control and interference suppression.Let’s first talk about power consumption control: In mobile communications, in view of the changes in the distance between the two ends and the different levels of interference, for the transmitter, it is only necessary to maintain the signal strength enough for the receiver of the other party to demodulate accurately. If it is low, the communication quality is impaired, and if it is too high, the empty power consumption is meaningless. This is especially true for battery-powered terminals like mobile phones.Interference suppression is a more advanced requirement. In CDMA-type systems, because different users share the same carrier frequency (differentiated by orthogonal user codes), in the signal arriving at the receiver, user's signal is covered by the same frequency for other users. If the signal power of each user is high or low, the high-power user will drown out the low-power user’s signal. Therefore, the CDMA system adopts a power control method to control the power of different users reaching the receiver, and sends a power control command to each terminal to make the air interface power of each user the same. This kind of power control has two characteristics: the first is that the power control accuracy is very high (the interference tolerance is very low), and the second is that the power control cycle is very short (the channel may change quickly).In the LTE system, uplink power control also has the effect of interference suppression. Because LTE uplink is SC-FDMA, and multiple users also share carrier frequencies, which also interfere with each other, so the same air interface power.The GSM system also has power control. In GSM, we use power level to characterize the power control step length, each level is 1dB. It can be seen that GSM power control is relatively rough.Interference Limited SystemHere is a related concept: interference limited system. The CDMA system is a typical interference limited system. In theory, if each user code is completely orthogonal and can be completely distinguished by interleaving and de-interleaving, then the capacity of the CDMA system can be infinite. Because it can be used on limited frequency resources. The user code extended layer by layer distinguishes an infinite number of users. But in fact, since the user codes cannot be completely orthogonal, noise is inevitably introduced during multi-user signal demodulation. The more users there are, the higher the noise will be, until the noise exceeds the demodulation threshold. In other words, the capacity of the CDMA system is limited by interference (noise).The GSM system is not an interference limited system, but a time-domain and frequency-domain limited system. Its capacity is limited by frequency (a carrier frequency of 200kHz) and time domain resources (8 TDMAs can be shared on each carrier frequency user). Therefore, the power control requirements of the GSM system are not strict. 1.9.5 Transmitter Power Control and Transmitter RF Indicators Next, let's discuss the factors that may affect the transmitter power control in the RF design.For RF, if the power detection (feedback) loop design is correct, then we can do not much for the transmitter closed-loop power control (most of the work is done by the physical layer protocol algorithm), and the most important thing is the flatness in the transmitter band.Because the transmitter calibration can only be carried out on a limited number of frequency points, especially in the production test, the less frequency points the better. However, it is entirely possible for the transmitter to work on any carrier in the frequency band in practice. In a typical production calibration, we will calibrate the transmitter's frequency points to keep accuracy. So the closed-loop power control is correct at the calibrated frequency points. However, if the transmit power is not flat in the entire frequency band, some frequency points deviates greatly from the calibration frequency point. Therefore, the closed-loop power control with the calibration frequency point as a reference will have errors and even mistakes.   Ⅱ FAQ 1. What is RFID and how it works?RFID tags transmit data about an item through radio waves to the antenna/reader combination. ... The energy activates the chip, which modulates the energy with the desired information, and then transmits a signal back toward the antenna/reader. 2. What is RFID used for?RFID tags are a type of tracking system that uses radio frequency to search, identify, track, and communicate with items and people. Essentially, RFID tags are smart labels that can store a range of information from serial numbers, to a short description, and even pages of data. 3. Is RFID harmful to human?Electromagnetic fields generated by RFID devices—touted as a patient-safety technique to keep track of supplies, medical tests and samples, and people—could cause medical equipment to malfunction, according to a recent study of medical devices in Amsterdam published in the June 25 Journal of the American Medical. 4. What is RFID example?For example, an RFID tag attached to an automobile during production can be used to track its progress through the assembly line, RFID-tagged pharmaceuticals can be tracked through warehouses, and implanting RFID microchips in livestock and pets enables positive identification of animals. 5. What are the components of RFID?Every RFID system consists of three components: a scanning antenna, a transceiver and a transponder. When the scanning antenna and transceiver are combined, they are referred to as an RFID reader or interrogator. 6. Who discovered RFID?Charles WaltonRFID was, however, officially invented in 1983 by Charles Walton when he filed the first patent with the word 'RFID'. NFC started making the headlines in 2002 and has since then continued to develop. 7. How is RFID made?The antenna can be made of etched copper, aluminum or conductive ink, while the chip and antenna are typically put on a substrate that is PET or paper. ... Usually, this inlay is inserted into a printable label to create an RFID transponder that can be affixed to a product. 8. Where did RFID come from?The First RFID PatentsMario W. Cardullo claims to have received the first U.S. patent for an active RFID tag with rewritable memory on January 23, 1973. That same year, Charles Walton, a California entrepreneur, received a patent for a passive transponder used to unlock a door without a key. 9. What is a RFID system?Radio Frequency Identification (RFID) refers to a wireless system comprised of two components: tags and readers. ... Passive RFID tags are powered by the reader and do not have a battery. Active RFID tags are powered by batteries. RFID tags can store a range of information from one serial number to several pages of data. 10. What are the three parameters that define an RFID system?Every RFID system consists of three components: a scanning antenna, a transceiver and a transponder. When the scanning antenna and transceiver are combined, they are referred to as an RFID reader or interrogator. 11. What are the basic criteria in RFID?Many large organizations and government agencies have mandated that their suppliers provide goods with RFID tags. These published mandates may specify tag type, frequency, amount of memory, read range, read rate and speed, and protocol. In addition, the mandates may specify how the goods should be tagged. 12. What is the maximum read range of RFID module?Maximum read distance of 1.5 meters (4 foot 11 inches) - usually under 1 meter (3 feet) and you can use a single or multi port reader plus custom antennas to extend the read range to longer tag read distances or a wider RFID read zone. 13. What is RFID in supply chain management?+RFID (Radio Frequency Identification) is a form of extremely low-power data communication between a RFID scanner and an RFID tag. ... The tags are placed on any number of items, ranging from individual parts to shipping labels. 14. How many bits does an RFID tag have?It depends on the vendor, the application and type of tag, but typically a tag carries no more than 2 kilobytes (KB) of data—enough to store some basic information about the item it is on. Simple “license plate” tags contain only a 96-bit or 128-bit serial number. 15. Does RFID reader store data?An RFID tag can store large amounts of data additionally to a unique identifier • Unique item identification is easier to implement with RFID than with barcodes. • Its ability to identify items individually rather than generically.

The laminate substrates, one of the most widely used carriers in RF module packaging. This method that combines the traditional laminate substrates technology with the integrated passive device technology (IPD) is a win-win solution that can achieve the best balance in cost, size, performance, and flexibility. The application of laminate substrates with IPD devices is discussed with two examples in this article.     Catalog I. General Introduction II. Comparison of IPD and SMD(Surface Mounted Devices) and LTCC Discrete   Device Circuits III. Application Examples IV. Conclusion FAQ   I. General Introduction   A wide range of packaging carrier technologies are available in radio frequency packages(hereinafter referred to as RF) and wireless products, including lead frames, laminate substrates, low-temperature co-fired ceramic (hereinafter referred to as LTCC), and silicon backplane. Because the increasing function has higher requirements for integration, also more demands put forward for the system-level packaging method (SiP). Lead frame substrate packaging technology has been greatly developed in the past few years, including etching inductors, adding passive devices to pins, stacking technology of chips, and so on. Frame substrates are the cheapest cost option, but higher functionality requires more wiring and more vertical space utilized, therefore framework package is rarely used in RF integration solutions.   LTCC has been proven to be a high-performance substrate material that provides high integration due to its multi-layer structure, the high dielectric is constant, and high-quality factor inductance. The passive device can be embedded in LTCC, such as independent RCL or functional blocks containing RCL, so that SMT(surface mounted technology) devices require minimal planar space and improved electrical performance.   Integration is the advantage of LTCC, however, warping, cracks, secondary reliability of substrate, and the whole supply chain structure (transfer of substrate during packaging) limit the LTCC, which makes it impossible to become a popular carrier substrate selection.   Silicon substrate carriers, such as the chip-scale module package(CSMP) of STATS ChipPAC, have been widely used in wireless solutions requiring high integration, excellent electrical performance, and small profile coefficients. CSMP is an ideal packaging form of a fully integrated solution that can include RFIC and baseband IC. However, such integration is not the lowest cost and is not required for all RF and wireless devices.   The above-mentioned reasons lead us to think of the laminate substrates, one of the most widely used carriers in RF module packaging. This method that combines the traditional laminate substrates technology with the integrated passive device technology (IPD) is a win-win solution that can achieve the best balance in cost, size, performance, and flexibility. The application of laminate substrates with IPD devices is discussed with two examples in this article.     II. Comparison of IPD and SMD(Surface Mounted Devices) and LTCC Discrete Device Circuits   RF modules need independent RCL or combined RCLs to implement functional blocks such as filters, diplexer, balun, which are usually the SMD or IPD.   The traditional laminate substrate is not suitable for embedded passive devices, and high dielectric material lamination is limited by large cost. Spiral inductors can be designed inside the laminate substrate, but the inductance is limited. Therefore, laminate substrates are more likely to combine SMT with IPD, which has the advantages of cost, shape size, performance, and so on.   It needs to trade-off when SMDs be used and when specific passive devices are designed into reasonable IPDs. For example, when a capacitor larger than 100.0pF is required, the use of SMT devices has the advantage of size and cost.   In addition, SMT passive devices are generally recommended when a small number of decoupling capacitors or independent inductors and resistors are required in the design. The surface mount device can make full use of the Z direction of the occupied space while the IPD mainly uses the XY direction, the latter has very limited utilization of the Z height direction.   Thus it is wise to use SMT devices when the surface area of the IPD devices exceeds the available space. In order to find the best balance between IPD and SMT devices, a curve describing the relationship between the device value and the area required by IPD is developed (Fig. 1) for design reference.   Fig.1 Inductance and Capacitance of IPD fabricated on Silicon substrate Using silicon-based IPD technology, an 0201 SMD device (0.15mm2) can generate a 25.0nH inductance value or 50.0pF capacitance value. In other words, If the capacity is smaller than these two values, the external dimensions of the devices/circuits scheme are smaller than that of 0201 devices.   IPD schemes are suitable for functional blocks for a variety of reasons. First, although the silicon-based IPD inductor also uses a spiral form, it can use smaller linewidth and isolation space. In addition, high-resistive silicon substrates are allowed to produce higher-quality inductors.   As a result, the mass and shape coefficients of an IPD inductor are comparable to those of SMD devices. Second, small-capacity capacitors (in RF applications) are easier to build in IPD. Finally, comparing with connecting SMD devices with PCB, or internal connections to LTCC, the interconnect paths on silicon substrates are shorter.   For an ultra-wideband (UWB) application filter, as an example, the existing LTCC filter size is 3.2mm × 2.5mm × 0.8mm, and if the same layout is used in IPD, the size will be 1.6mm × 1.0mm × 0.5mm (Figure 2). IPD filter has a thinner shape and its size has been reduced by five times. Fig.2 Size Comparison between LTCC Filter and IPD Filter Comparing with other cases, for filters (such as LPF or BPF), IPD can get five times smaller shapes; for unbalanced transformers, using IPD shape can be two times smaller.   Another way is to use embedded inductors (inside laminates) and SMT capacitors to make filters, but in this way means occupying more space than LTCC or IPD, also including performance limitations.   In addition, since the process of assembling a whole integrated functional block is split into two parts (PCB inductor and SMT capacitor), the package requirements must be stricter for the assembly processes.   SMT devices have different sizes. In the RF module application, the most commonly used is 0201. Smaller 01005 devices have just appeared, but they are usually more expensive and have limited device value.   These SMT devices are usually attached to the laminate using a high-speed mounting machine, which is then soldered back to the laminate.   Fig. 3 An IPD are Bonded on A Laminated Substrate or Upside Down on It in an RF Module The IPD can be in the form of a bare chip or a convex device and then welded to the substrate by wire bonding or inversion (Fig. 3). The convex IPD chip and SMT device can be pasted by a high-speed mounting machine. After finished, the other chips can be directly placed on the substrate by wire bonding.   III. Application Examples   Example 1—GSM Matching Circuit In an RF receiver, matching circuits are needed to improve the performance of PA and LNA active circuits. These matching circuits include RCL devices. Considering cost and performance, these RCL devices can be removed from the chip and implemented in the form of SMD or IPD.   We compare a client's GSM transport module with an out-of-chip adaptor. In this module, there are 73 passive devices for matching circuits and DC decoupling. If only SMD elements are used (assuming all devices can be 0201), the package size will be 11mm × 11mm. However, if some devices are implemented in the form of IPD, the size of the module can be significantly reduced (Table 1).   Table.1 Package Size Comparsion between SMD and IPD+SMD IPD is very suitable for the low frequency (860MHz) and high frequency (1800MHz) adapters of GSM. In addition to some large capacity decoupling capacitors, 55 RCLs can be made in a smaller IPD network, which the package size can be only 7mm × 7 mm. In order to simplify, the complexity of routing is not taken into account in all examples.   It should be noted that the IPD network is treated as an integrated chip because its shape coefficient and thickness are similar to that of an integrated circuit.   IPD network is stacked with the transport chip, although it increases the thickness of the module, the IPD thickness is only 0.25mm, thus there is no obvious effect on the thickness increase (although it increases the thickness of the module when the IPD network stacked with the transport chip, there is no obvious effect on the thickness as the IPD thickness is only 0.25mm).   Therefore, the IPD packaging stack saves space and can be stacked on top or bottom of another chip by wire bonding or flip-chip bonding.   Example 2—GSM Balun Circuits In order to suppress the noise and improve the PA performance, differential output settings are often used for PA, thus a transformer is needed to convert the single-step terminal to the differential one. However, transformers that can be supplied by the industry have a fixed impedance transformer ratio, such as 50.0~100. 0 Ω transformers or 50.0~200. 0 Ω transformers.   Most PAs have low output impedance to transmit high power, which requires a matching circuit between the transformer and PA, as shown in figure 5 (b). In this example, the output matching circuit and transformer function block of PA are used to demonstrate the effects of IPD technology.   Fig.4 Package Comparison of Two Schemes There are GSM low frequency (860 MHz) and high frequency (1800 MHz) circuits in the application. Different frequencies have different matching circuits and transformers to convert a differential-terminal output to a single-step output (50.0Ω). In the existing form of the product, a customer uses a standard chip LTCC transformer with dimensions of 2.0 mm * 1.25 mm * 0.95 mm and 1.6 mm * 0.8 mm * 0.8 mm * 0. 6 mm.   Because the standard transformer has 50.0Ωto 200.0Ωimpedance conversion and does not match the specific power amplifier output impedance, the module needs to be independent with a 4RCL device. The current LTCC + SMD solutions are shown in Table 2.   Table.2 Size Comparsion between IPD and LTCC + SMD     Because an IPD transformer can be designed to match any amplifier output impedance, there is no need to use a separate matching circuit (4 RCL) to each frequency band. In other words, the matching function can be embedded into the Balun transformer.   The overall size of the IPD scheme is 2.5 mm2, which is about four times smaller than the size of the existing LTCC+SMD scheme. In addition, the matchers and transformer circuits are only about 0.25mm high, which is also thinner than discrete LTCC devices.   Fig.5 (a) IPD Balun in the high and low frequency band of GSM, the sizes are 1.5mm*1.0mm and 1.0mm * 1.0mm, and Matching function has been embedded in Balun transformer. Figure 5 (b) The function-block solution of output matching circuit and transformer. IPD solution eliminates the use of SMD devices completely in matchers and transformer modules. It not only reduces the area by four times but also greatly cuts the cost of the packaging process. Because it is integrated into an IPD module instead of using a LTCC separator, balun transformer, and four RCLs, the effects of yield and process changes are improved.   IV. Conclusion     There have been many studies on the ideal solution of RF packaging in recent years, and the most important thing is to strike a balance between cost, volume, and performance. Although remarkable progress has been made in the lead frame technology, the performance of the LTCC substrate has been improved. The technology of IPD integration and laminate substrates is still the best considerate solution.   Laminate substrates have low cost, high flexibility, mature supply chains, and fast manufacturing cycles. IPD can produce excellent RF functional blocks and can be mounted on laminate substrates as easily as chips or SMT devices. Combining laminate substrates with IPD provides a very broad range of RF solutions. The two GSM examples studied in this article are just illustrating the typical size reduction. This technology can also be used in RF circuits of mobile TV, GPS, WLAN, and WiMax devices.     FAQ   1. What is RF and how it works? Radio frequency waves (RF) are generated when an alternating current goes through a conductive material. ... Frequency is measured in hertz (or cycles per second) and wavelength is measured in meters (or centimeters). Radio waves are electromagnetic waves and they travel at the speed of light in free space.   2. How do RF modules transmit data? An RF transmitter receives serial data and transmits it wirelessly through RF through its antenna connected at pin4. The transmission occurs at the rate of 1Kbps - 10Kbps. The transmitted data is received by an RF receiver operating at the same frequency as that of the transmitter.   3. How does RF transceiver work? RF transceiver module is used in a particular device where both the transmitter and receiver houses in a single module. Such devices transmit and receives RF signal, so that is named as RF Transceiver. ... The transmitter and Receiver parts in the RF transceivers called as RF Up converter and RF Down converter.   4.What is RF transmitter and receiver? RF signals travel in the transmitter and receiver even when there is an obstruction. It operates at a specific frequency of 433MHz. RF transmitter receives serial data and transmits to the receiver through an antenna which is connected to the 4th pin of the transmitter.   5. Is RF dangerous? RF radiation has lower energy than some other types of non-ionizing radiation, like visible light and infrared, but it has higher energy than extremely low-frequency (ELF) radiation. If RF radiation is absorbed by the body in large enough amounts, it can produce heat. This can lead to burns and body tissue damage.   6. Why is RF used? RF energy in more specific applications, like in the medical field, have equally specified purposes. MRI (Magnetic Resonance Imaging) uses RF waves to generate images of the human body. RF is also used to destroy cancer cells and perform cosmetic treatments that tighten skin, reduce fat, or promote skin cell healing.   7. Is WIFI a RF? Very basically, Wi-Fi is made up of stations that transmit and receive data. Wireless transmissions are made up of radio frequency signals, or RF signals, which travel using a variety of movement behaviors (also called propagation behaviors).   8. How is RF signal transmitted? As the RF waves move away from the transmitting antenna they move towards another antenna attached to the receiver, which is the final component in the wireless medium. The receiver takes the signal that it received from the antenna and translates the modulated signals and passes them on to be processed.   9. What devices use RF? Modern devices often generate electromagnetic fields of radio frequency (RF) ranging from 100 kHz to 300 GHz. Key sources of RF fields include mobile phones, cordless phones, local wireless networks and radio transmission towers. They are also used by medical scanners, radar systems and microwave ovens.   10.How far can RF travel? The distance a radio wave travels in a vacuum, in one second, is 299,792,458 meters (983,571,056 ft), which is the wavelength of a 1 hertz radio signal. A 1 megahertz radio wave (mid-AM band) has a wavelength of 299.79 meters (983.6 ft).   11. What RF sensing? Unlike traditional hardware sensors, RF sensing provides users with low-cost and unobtrusive services. Fur- thermore, due to the broadcast nature of RF sig- nals, RF sensing can be used not only to monitor multiple subjects, but also to capture changes in the environment over a large area.   12. What is the frequency range of RF? Radio frequency (RF) is the oscillation rate of an alternating electric current or voltage or of a magnetic, electric or electromagnetic field or mechanical system in the frequency range from around 20 kHz to around 300 GHz.   13. How do you calculate RF? The Rf value of a compound is equal to the distance traveled by the compound divided by the distance traveled by the solvent front (both measured from the origin).   14. How do I connect RF headphones to my TV? On the back of the headphone transmitter, connect the other end of the audio cable to the AUDIO IN jack. Connect the AC adapter into the transmitter's DC IN 9V jack and then plug it into a wall outlet. Adjust the TV volume to the desired level. Turn on the wireless headphones and adjust the volume to the desired level.   15. What is the difference between RF and IR? RF (radio frequency) technology uses radio waves to transmit the audio signal. These are susceptible to RF interference. IR (infrared) technology uses infrared light to carry the audio signal thus keeping the signal in the room and eliminating RF interference.   You May Also Like How Does RFID Make An Impact On Retail Industry Basic Introduction and Future Development Trend Analysis of RFID Technology Powercast Announced The Industry’s First RFID Sensor Tags Which Can Include Multiple Sensors in A Single Tag

Radio Frequency Identification (RFID) technology has been developed rapidly in recent years. The key is an automatic identification technology which uses radio waves to communicate. Compared with the traditional recognition technology, it has the advantages of fast recognition, large data storage and data updatable.  This is a video about brief introduction to RFIDThe basic principle of the data communication is the electromagnetic coupling between the reader and the electronic tag affixed to the object. This article will take the RFID technology as the research object, analyzing the basic definition of RFID, the components of the system, the working principle, operating frequency, the main application examples and development trend of RFID technology. In this article, we will make some intorduction to RFID and analyze how it will develop in the future.  CatalogI What is RFID?II Structure of RFID system2.1 Basic components of RFID2.2 RFID middlewareIII Basic working principle of RFID   technologyIV RFID operating frequency4.1 Low frequency 4.2 High Frequency4.3 Ultra-high frequency4.4 Active RFID technologyV RFID practical application examples5.1 Necessity of applying RFID technology   to retail logistics5.2 Why to use RFID technology instead of   existing technology5.3 Application of RFID technology in   retail industryVI Development trend of RFID application   system6.1 More powerful system compatibility6.2 System networking6.3 Greater system data volume6.4 High frequency systemFAQI What is RFID?Radio Frequency Identification (RFID) technology, also known as electronic tag, is a communication technology that uses radio signals to identify specific targets and read and write related data. And there is no need to identify the mechanical or optical contact between the system and the specific target. It can achieve fast reading and writing, non-visual recognition, mobile recognition, multi-target recognition, locating and long-term tracking management. The recognition work is not affected by bad environment, and it can achieve fast reading speed, read information safe and reliable. Therefore, RFID technology has a wide range of application prospects. Radio frequency identification is a non-contact automatic identification technology. It can automatically identify the target object and obtain the relevant data through the radio frequency signal. The identification work can be applied to all kinds of bad environment. RFID is a simple wireless system with only two basic devices. It is used to control, detect and track objects. The system consists of an interrogator and many transponders.Due to the rapid development of RF technology, transponders are also called smart tags or tags. The RFID reader can communicate wirelessly with the electronic tag through the antennas, and can read and write the tag identification code and memory data. A typical reader includes a high-frequency module, a control unit and a reader antenna. II Structure of RFID system2.1 Basic components of RFIDRFID system mainly includes four parts: electronic tag, reader, antenna and application software. The following picture is the block diagram of the system:RFID system structureFrom the above diagram, we can see that there are input and output of data in the module of reader and electronic tag, and the energy and clock are also transmitted in the two modules.2.1.1 ReaderReader is a device for reading (or writing) tag information that can be designed to be hand-held or fixed type. Hand-held is a smaller type used by supermarket cashiers; Fixed is a stationary reader placed by a logistics company at the door when goods are stored in a warehouse. As soon as the object swept by, the scan was completed in an instant.Reader working model2.1.2 AntennaAntenna is used to transmit RF signals between tags and readers.2.1.3 TagsTags are made up of coupling elements and chips. Each tag has a unique electronic code attached to an object to identify the target object. The following picture is the query tag diagram of readers. Reader query tag diagram2.1.4 Application softwareApplication software is a part of RFID system, which is software developed for different needs. It can read, write and control electronic tags through readers, and process and count the collected data. 2.2 RFID middlewareIn the application program, the API can connect to the RFID reader and retrieve the data from the RFID tag through the universal application program interface which can be provided by middleware. RFID middleware acts as a bridge between RFID tags and applications.In this way, even when the FRID reader category or application changes, the application still doesn't need to make any changes. It just need to configure the middleware accordingly. This can reflect the flexibility and importance of middleware.Practical application of RFID middlewareThe benefits that the application of RFID middleware can be brought to an enterprise are as follows:- According to their own business requirements and actual usage, enterprises can import the required data into the application software by self-configuring the RFID middleware parameters, which can fully reflect the flexible characteristics of RFID middleware.- The import of RFID data only needs to change the setting of RFID middleware when some changes occur in enterprise application software.- If you need to increase the number of RFID readers, then enterprises only need to do some related RFID middleware settings. It doesn’t need to change any related procedures, which reduce unnecessary trouble, and save time.- It shortens the implementation cycle of RFID application, and enterprises can directly import the relevant data of RFID.  III Basic working principle of RFID technologyA complete RFID system is composed of three parts: reader, tag with transponder and application software system. Its working principle is: Reader sends out the energy of a radio wave at a specific frequency to drive the transponder, and the circuit will send out the internal data. At this time, the reader will receive the data in order and interpret them, then send it to the application for some corresponding processing.RFID working principleThe information exchange between the reader and the transponder is usually half-duplex communication mode. In this case, the reader can provide the passive transponder with energy, timing and other related contents by coupling. In practical application, the object recognition information can be collected, processed and transmitted remotely through Ethernet and so on. Transponder is the main information carrier of its system. At present, most of the transponders in the market are composed of coupling elements (including coils, microstrip antennas, etc.) and passive application units composed of microchips. The reader can control and process the information center according to the structure and technology of RFID system information. Its reader is usually composed of a transceiver module, a coupling module, an interface unit and a control module. IV RFID operating frequencyAt present, the operating frequencies of RFID products are divided into low frequency, high frequency, ultra high frequency and so on. RFID products with different frequencies will have different characteristics. 4.1 Low frequency (125KHz ~ 135KHz)Related operation at this frequency is mainly done by inductive coupling. There is a transformer coupling between the inductor coil and the reader coil. The voltage which can be induced in the antenna of the inductor can be rectified by the action of the relative alternating field of the reader. Features:- Apart from some related effects of metal materials, the general low-frequency system can penetrate any material, but it will not reduce its maximum possible reading distance.- Readers working at low frequencies have no special licensing restrictions on the entire planet.- Low-frequency products have different packaging forms. The disadvantage of the best package is that it is too expensive, but it has a service life of more than 10 years.- The frequency of the sensor working in low frequency ranges from 120KHz to 134 kHz. The wavelength of this band is about 2500m. 4.2 High frequencySensors at this frequency will no longer need a coil to wrap it up. Antennas can be made by etching or printing. The related operations of sensors are usually done by load modulation. That is, by turning on and off the load resistance on the inductor, the voltage on the reader antenna will be changed, which can realize the amplitude modulation of the antenna voltage with the remote inductor. If people use data to control load voltages on and off, the data can be transmitted quickly from the sensor to the reader.Features: - Apart from metallic materials, the wavelength of this frequency can pass through most materials, but it will reduce the reading distance. Sensors often need a distance away from the metal.- Although the magnetic field region at this frequency decreases rapidly , a relatively uniform read - write region can be produced.- The system has good anti-collision property and can read many electronic tags at the same time.- Sensors usually exist in the form of electronic tags. 4.3 Ultra-high frequencyThe ultra-high frequency system will transmit energy by electric field. The energy of the electric field will not decrease rapidly. The reading distance of UHF is relatively long, and the passive system can reach about 10m. It is mainly realized by capacitive coupling.Features: - This frequency band has a good reading distance, but it is difficult to define the reading region.- It has a particularly high rate of data transmission and can read a large number of related electronic tags in a very short time.- The radio waves in the UHF band cannot pass through many kinds of application materials, especially water, dust and other substances. For high-frequency electronic tags, however, the tags need not be separated from metals.- Tag antennas are usually in two forms: long stripes and tags. The antenna has two different shapes: linear and circular polarization. It is designed to meet the needs of different applications in the market. 4.4 Active RFID technologyActive RFID is characterized by large amount of data transmission, long communication distance, high reliability, low transmitting power and good compatibility. Compared with passive RFID, it has obvious technical advantages.The basic ideas of RFID technology are: By adopting advanced technical means, people can automatically identify and manage all kinds of objects and equipment in different states.As a new kind of automatic identification technology, RFID technology has a great potential space for development in China, and it has been applied and developed in radio technology. V RFID practical application examplesIn this chapter, we will mainly expound the logistics analysis of retail industry based on RFID technology.5.1 Necessity of applying RFID technology to retail logisticsThe benefits of using RFID technology are not limited to the benefits of retail itself. With the use of RFID technology to create a new revenue stream, government institutions can reduce the loss and enhance the safety and security. At the same time, logistics companies, library systems can also reduce inventory costs.The application of RFID technology in retail can obtain the following benefits:   - Increase project securityTag items only allow objects to be tracked in a specified range or device. RFID technology can also improve the efficiency of inventory management. After all, inventory management is often a time-consuming and exhausting business for retailers.  - Serialization DataEach item has its unique identification number, so it is convenient to distinguish it from other items.  - Real time information flowThe changing state of a project can be quickly updated throughout the supply chain.  - Reduced manual participationRFID technology can track objects automatically without manual counting , data acquisition and bar code scanning , which can save labor cost and human error. The RFID technology provides a real-time visualization technology that allows inventory managers to monitor inventory supplies in real time. This reduces inventory costs and keeps inventory at an optimal level, which avoids shortage and other phenomena at the same time. 5.2 Why to use RFID technology instead of existing technologyThe question now is: why did retail change existing technology by adopting RFID? RFID technology is very similar to the existing bar code technology and non-contact memory. The use of new technologies can bring financial benefits (such as saving money) and can solve some practical problems that can not be solved by the existing technology. Compared with other automatic recognition techniques, RFID has significant advantages. 5.3 Application of RFID Technology in Retail industryRFID technology has been used in the retail industry such as smart shelf. The smart shelf is a kind of shelf which can prevent the phenomenon of product shortage. The shelf combines the RFID reader. Each unit shelf has a RFID tag that allows readers to track the inventory of their products. The main purpose of smart shelf is to support the replenishment at any time and to keep the shelves never out of stock, thus it has been widely used in retail industry and libraries. On one hand, it provides customers with information about the products; on the other hand, it provides inventory information for retail owners and can accurately locate the goods. The purpose of these applications is to offer better and more effective service to them. The use of these technologies will not be limited. It can make customers feel more effective and easier to shop.VI Development Trend of RFID Application systemIt can be predicted that future RFID systems will have the following technological trends: 6.1 More Powerful System CompatibilityAt present, because of the disunity of standards, products from many manufacturers are incompatible with each other. Therefore, it is required that the system should have a very strong compatibility, so that it can deal with the products of multiple manufacturers. 6.2 System NetworkingIn many applications, the data collected by different systems need to be processed uniformly, and then provided to users for use, which requires the management of RFID systems on a networked basis. The aim is to realize the remote control management of the system. 6.3 Greater System Data VolumeThe future RFID system will deal with a large amount of data, so it is necessary for the system to have a stronger data storage capacity and data processing capacity. 6.4 High frequency systemThe UHF RFID system has many advantages compared with the low frequency system, such as small size, long recognition distance, repeatable reading and writing, and no forgery. Therefore, with the decrease of manufacturing cost, the application of UHF system will be more extensive.  FAQ 1. What is RFID used for?Radio Frequency Identification (RFID) is the wireless non-contact use of radio frequency waves to transfer data. Tagging items with RFID tags allows users to automatically and uniquely identify and track inventory and assets. 2. What is RFID and how it works?RFID is a method of data collection that involves automatically identifying objects through low-power radio waves. Data is sent and received with a system consisting of RFID tags, an antenna, an RFID reader, and a transceiver. 3. What RFID means?Radio Frequency Identification (RFID) refers to a wireless system comprised of two components: tags and readers. The reader is a device that has one or more antennas that emit radio waves and receive signals back from the RFID tag. 4. Is RFID harmful to human?It is a non-ionizing type of radiation, but some researches show that it could have a negative impact on the human body in a long-term period [11, 12]. So, for the safety reasons, manufacturers of the RFID systems have limited the range of the RFID antennas used in their systems. 5. Is RFID tag and FASTag same?FASTag is a device that employs Radio Frequency Identification (RFID) technology for making toll payments directly while the vehicle is in motion. FASTag (RFID Tag) is affixed on the windscreen of the vehicle and enables a customer to make the toll payments directly from the account which is linked to FASTag. 6.What is RFID and its advantages?RFID technology automates data collection and vastly reduces human effort and error. RFID supports tag reading with no line-of-sight or item-by-item scans required. RFID readers can read multiple RFID tags simultaneously, offering increases in efficiency. 7. Why is RFID bad?Some negative effects are that its deadly, if RFID tags combine with static electricity you can die. Another negative effect is that the government is slowly taking away surviving resources and giving ultimatums, such as if you don't get the RFID tracking chip your public assistance will be terminated. 8.What are the disadvantages of RFID?a. Materials like metal & liquid can impact signal.b. Sometimes not as accurate or reliable as barcode scanners.c. Cost – RFID readers can be 10x more expensive than barcode readers.d. Implementation can be difficult & time consuming. 9.How do I charge my RFID FASTag?In order to recharge your FASTag sticker, just hit the Add Money option in your Paytm app. FASTag will automatically reserve some amount from your wallet, which can be used at toll plazas later. Do note that FASTag can be used only after 20 mins of adding money to the Paytm Wallet. 10. Can I use existing RFID for FASTag?If a vehicle already has an RFID tag, it might already be activated. When you buy the vehicle, RFID tag payment was also done. It might also have a minimum balance of INR 100 or 200 as is required by the bank. You can recharge it with your Customer ID or Wallet ID of FASTag. 11. How does RFID work without power?Passive RFID tags have no power of their own and are powered by the radio frequency energy transmitted from RFID readers/antennas. The signal sent by the reader and antenna is used to power on the tag and reflect the energy back to the reader. 12. What are the types of RFID tags?RFID tags can be grouped into three categories based on the range of frequencies they use to communicate data: low frequency (LF), high frequency (HF) and ultra-high frequency (UHF). Generally speaking, the lower the frequency of the RFID system, the shorter the read range and slower the data read rate. 13.How do I know if I have an RFID chip?The best way to check for an implant would be to have an X-ray performed. RFID transponders have metal antennas that would show up in an X-ray. You could also look for a scar on the skin. Because the needle used to inject the transponder under the skin would be quite large, it would leave a small but noticeable scar. 14. Does RFID require power?Active RFID tags possess their own power source – an internal battery that enables them to have extremely long read ranges as well as large memory banks. Typically, active RFID tags are powered by a battery that will last between 3 - 5 years, but when the battery fails, the active tag will need to be replaced. 15. What is the difference between a QR code and RFID?QR codes must always be “read-only”, whereas RFID tags can be “read-write”, depending on the radio frequency that's being used. ... So, not only are RFID tags futuristic and have more uses than QR tags, they also have many more applications. The read range is far superior for an RFID tag.
